GEOMETRY
|
S |
M |
L |
|
|
SEAT TUBE (C-T) |
405 |
450 |
500 |
|
TOP TUBE (EFF) |
625 |
648 |
693 |
|
HEAD TUBE |
190 |
240 |
270 |
|
CHAINSTAY |
510 |
510 |
|
|
BB HEIGHT |
272,5 |
272,5 |
272,5 |
|
BB DROP |
95 |
95 |
95 |
|
WHEELBASE |
1163 |
1187 |
1233 |
|
HEAD ANGLE |
70° |
70° |
70° |
|
SEAT ANGLE |
72° |
72° |
72° |
|
REACH |
397 |
405 |
440 |
|
STACK |
662 |
709 |
737 |
|
FORK LENGTH |
433 |
433 |
433 |
|
RAKE |
55 |
55 |
55 |
